Features
* Integrated with demodulation and gateway function
* Support 8 channels tuner (ASI) input
* Support BISS descrambling (Up to 120Mbps)
* 1 GE output, maximum output bit-rate is 800Mbps
* SPTSx32 or SPTSx20 (For version with BISS function) over
   UDP, RTP/RTSP, unicast and  multicast
* Supports LCD display and keyboard
* Supports SNMP/Web operation

Input
8 tuner input DVB-S/DVB-S2

Output
1 GE output, UDP, RTP/RTSP protocol, unicast and Multicast
32 SPTS output — Without BISS function
Or 20 SPTS output — With BISS function

BISS
descrambling
Mode 1, Mode E
Transmission Bit-rate Maximum total bit-rate is 800Mbps

General
Dimensions (WxLxH) 482mm×410mm×44mm
Weight  5.5kg
Operating Temperature 0-45 deg (working )，-20-80 deg( storage)
Power supply 100-240VAC，50/60Hz
