CPU- Allwinner H313 Quad Core ARM Cortex A53
GPU- G31 OPenGL3.2
Memory- DDR3：2GB
Flash- eMMC：16GB
WiFi- IEEE 802.11 b/g/n, 2.4+5G WiFi Bluetooth
Case- Plastic : Black Colour
Outputs
1 x HD- 4K/2K UHD Output, HD 2.0A
1 x AV OUT 480i/576i standard definition output
2 x USB 1 x USB Host Port ,1 x USB Device
1 x RJ45 Ethernet Interface
1 x TF CARD slot, Supports 4GB/8GB/16GB/32GB/64GB
Power- DC 5V/2A；LED indicator，Working ：Blue; Standby：Red
SOFTWARE
OS- AndroidTV 10.0
Video Engine (AVE) with dedicated hardware decoders and encoders
Supports multi-video decoder up to 4K@60fps
Supports multiple “secured” video decoding sessions and simultaneous
decoding and encoding
Video/Picture Decoding
– VP9 Profile-2 up to 4K@30fps
– H.265 Main10@L5.1 up to 4K@60fps
– AVS2 JiZhun 10bit Profile up to 4K@60fps
– H.264 BP/MP/HP@L4.2 up to 4K@30fps
– H.263 BP up to 1080P@60fps
– MPEG-4 SP/ASP@L5 up to 1080P@60fps
– MPEG-2 MP/HL up to 1080P@60fps
– MPEG-1 MP/HL up to 1080P@60fps
– Xvid up to 1080P@60fps
– Sorenson Spark up to 1080P@60fps
– VP8 up to 1080P@60fps
– AVS/AVS+ JiZhun Profile up to 1080P@60fps
– WMV9/VC1 SP/MP/AP up to 1080P@60fps
– JPEG HFIF file format up to 45M PPS
– Multiple language and multiple format sub-title video support
– MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
Audio
* Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with
7.1/5.1 down-mixing
* Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output
• Two DAC channels
• Supports 1 audio output interface (differential LINEOUTP/N or single-end
LINEOUTL/LINEOUTR)
• One Audio HUB, supporting internal mixing function
• Embedded 3 I2S/PCM (I2S0 for extended audio codec, I2S2 for BT, I2S3
for digital power amplifier)
• Supports Left-justified, Right-justified, Standard I2S mode, PCM mode,
and TDM mode
• I2S mode supports 8 channels, and 32-bit/192kbit sample rate
• I2S and TDM modes support maximum 16 channels, and 32-bit/96kbit
sample rate
• One OWA OUT interface, supporting 16-/20-/24-bit inputs and outputs
• Integrated digital microphone(DMIC), supporting maximum 8 digital PDM
microphones
Image types
HD JPEG、BMP、GIF、PNG、TIF
Language
English French German Spanish Italian etc multilateral languages
