CPU System
• CPU: Quad Core 64Bit ARM Cortex A53
• Processor Frequency: up to 2.0GHz
• ARM v7 instruction set, multi-issue super scalar
• MB Unified L2 cache
GPU System
• GPU: Octa Core ARM Mali-450 up to 600MHz C DVFS)
• Dual Geometry Processors with 32KB L2 cache
• OpenGL ES 1.1 /2.0 and OpenVG 1.1 support
• Six Pixel Processors with 2x128KB L2 caches
• 3600Mpix/sec and 132Mtri/sec
Memory
• Flash: 2GB EMMC
• DOR: 1GB RAM DDR3-1600
• TF-card: up to 32GB
Video Decoding
• H.265 up to 1080p@60fps
• WMVNC-1 SP/MP/AP up to 1080P@60fps
• AVS JiZhun Profile up to 1080P@60fps
• Supports *.mkv,*.wmv,*.mp4,*.avi,*.iso,*.rm,*.mov file formats
• H.264 MVC up to 1080P@60fps
• MPEG-4 ASP@L5 up to 1080P@60fps
Audio Decoding
• Audio Codec: MPEG-1,MPEG-2(Layer l/ll),MP3,AC-3 (Dolby Digital), AAC-LC,WMA
• E-AC-3(Dolby Digital Plus) encoding
• HE-AAC 5.1 multi-channeldecoding
Connectivity
• Video: 1xHDMI, 1xCVBS (3.5mm Jack)
·Audio: 1xAudio L&R (3.5mm Jack), 1xS/PDIF
• Data Interface: 1xUSB3.0, 1xTF-card
• Internet interface: 1 xRJ45, 1 xWIFI module
• IR Interface: 1xExt-lR (3.5mm Jack)
• Power in: 1 x DC plug socket
Power
• Main power: 100-240VAC
• Power consumption: MAX 10W
Dimensions
• W x H x D (mm): 180 x 125 x 25
• Weight (Kg): 0.55
• Packaging dimension (mm):249 x 221 x 49
• Weight including packaging (Kg): 0.75
Accessories
• 1 x Remote Control Unit
• 2 x AAA Batteries
• 1 x 12V1.5A Power Adapter
• HDMI Lead
• 3.5mm CVBS Lead
