TECHNICAL SPECIFICATIONS

Made in Taiwan

Interfaces
Input- 4x HDMI, 4 x CVBS
Output- RF, UDP/RTP(Unicast/Multicast) 4XSPTS and 1XMPTS
Control- LCD with 6 keys & 1 x RJ45 (Web NMS)

Video Encoding
Format- HD:H.264AVC/HP@L4.0 SD:MPEG-2 MP/@ML
Resolution
Input: 1080 50/60p, 1080 50/60i, 720 50/60p, 480i, 576i
Output: up to 1080 30p
Bitrate- HDMI: 2~12Mbps CVBS: 2~6Mbps

Audio Encoding
Format- Mpeg1L2, AAC
Bitrate- 64 ~ 384Kbps
Sample Rate- 44.1KHz, 48.0KHz

Modulation
MER- Typ. 35dB
RF range- 100 to 950MHz, 1KHz steps
RF output level- 75 to 100dBµV

Standard- DVB-T
Bandwidth- 6, 7, 8M
Constellation- QPSK, 16QAM, 64QAM
Code Rate- 1/2,3/5, 2/3, 3/4, 5/6, 7/8
Guard interval- 1/4, 1/8, 1/16, 1/32
FFT- 2K, 8K

System
Management- LCD + Control buttons/Ethernet
Language- English
Upgrade- Ethernet

General
Multiplexing- PID remapping (automatically or manually)
Power Supply- AC 100~240V 50/60Hz
Display- LCD panel @ 2 x 16 characters LED X6 (Ch1~4+IP+RF)
Dimensions- 483 x 257 x 44.4mm
Weight- 2000g

Environmental
Operating- Temperature: 5°C- to 40°C
Relative Humidity: 80% @ 30°C
